Our SDK uses the native AJA SDK to work with AJA devices. Please ensure that you have installed the required SDK components for AJA and updated your drivers to the latest version.
Main features implemented:
- Input SDI/HDMI signals
- Output SDI/HDMI signals
- Internal and external keying
- Fill-only and Key-only outputs
- Closed Captioning (CEA-608, EIA-708, Line21)
- Bypass relays (check devices that support the feature)
- VANC data processing
- Timecode support
- Genlock support
The recommended AJA driver version for the latest Medialooks SDK is 17.5.
AJA SDK version history in Medialooks SDK:
| Medialooks SDK | Release Date | AJA SDK | Note |
|---|---|---|---|
| 2.9.2.14239 | May 2025 | 17.5 | x86 is deprecated |
| 2.8.1.13794 | May 2024 | 17.0 | |
| 2.7.3.13572 | Sep 2023 | 16.2.4.6 | |
| 2.5.0.12475 | June 2021 | 16.1 | |
| 2.0.3.11300 | July 2019 | 15.2.2 | |
| 2.0.1.11073 | Apr 2019 | 15.1 | |
| 2.0.0.11003 | Mar 2019 | 15.0.2 | |
| 1.7.17.10600 | Nov 2018 | 15.0 | |
| 1.7.16.10369 | Oct 2018 | 14.2 | |
| 1.7.10.9865 | Feb 2018 | 14.0.1 | |
| 1.7.5.9637 | Oct 2017 | 13.0 |
⚠️ Important Compatibility Notice:
Starting with Medialooks SDK 2.9.2.14239, AJA SDK 17.5 (x64 only) is required. AJA has officially discontinued x86 driver support.
AJA devices tested in our labs:
| Device | SD | HD | 4K UHD 30p |
CC | Keying | Known issues |
|---|---|---|---|---|---|---|
| Corvid 88 |
|
|
|
|||
| Corvid 44 |
|
|
|
|||
| Corvid 24 R1 |
|
|
||||
| KONA LHi |
|
|
||||
| KONA IP |
|
